Fracture load of nano-ceramic composite material for anterior endocrown restorations

Salma Alghalayini, Kamal Khaled Ebeid, Ayman Aldahrab, Marwa Wahsh


Objective: To evaluate ability of Nano Ceramic Composite endocrown to withstand occlusal forces when used in the anterior region. Material and Methods: Eighty endodontically treated maxillary central incisors teeth were randomly divided into two main groups according to the restoration type.  40 of these teeth were post, core and crown restorations and 40 were endocrown restorations.  Then they were divided by halves into two subgroups according to the material used 20 were made with Lava Ultimate and the other 20 with IPS e.max. Each subgroup was then further subdivided into two divisions according to the remaining tooth structure above the CEJ (n=10): 2 mm and 0.5 mm above the CEJ. After teeth preparation, the restorations were all made by CAD/CAM system (Cerec MCXL). All samples had undergone cyclic fatigue testing, and then loaded to fracture using a universal testing machine. The specimens were measured and statistically analyzed using Mann-Whitney test for comparing the mean changes between the groups. Results:  Lava Ultimate showed higher mean fracture load values than IPS e.max specimens. Conclusion: Endocrowns were found to be more favorable when used on endodontically treated teeth than the conventional post, core and crown restorations.


Endocrowns; All-ceramic; Fracture; Cyclic loading.
